Microchip's six ports PoE midspan provides up to 90 Watts of power over Ethernet and offers a IEEE 802.3bt-compliant solution for remote powering of current as well as emerging high power applications. The PD-9606GC is designed specifically to power IEEE 802.11 access points, pan-tilt-zoom (PTZ) and dome cameras, IP videophones, thin clients and other high power Ethernet end terminals with 90W of power. The solution supports IEEE 802.3bt powered devices and is also backward compatible and safe to use with any IEEE 802.3af/at terminal. It can power both existing 10/100Base-T devices and Gigabit devices. With the midspan's plug and-play installation, it is easy and cost-effective to implement leveraging existing Ethernet infrastructure while at the same time providing the assurance of a future-proof network.
- General Information
- Manufacturer
- Microchip Technology Inc.
- Manufacturer Website Address
- http://www.microchip.com
- Brand Name
- Microchip
- Product Type
- PoE Module
- Warranty
- Limited Warranty
- 3 Year
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Maximum Input Current
- 6 A
- Maximum Output Power
- 90 W
- Interfaces/Ports
- Input Ports
- 6 x Gigabit Ethernet
- Output Ports
- 6 x Gigabit Ethernet
- Physical Characteristics
- Form Factor
- Rack Mountable
- Height
- 44 mm
- Width
- 272 mm
- Length
- 438 mm
- Weight (Approximate)
- 4.54 kg
- Miscellaneous
- Package Contents
- 6 Ports, 90W, IEEE 802.3bt-Compliant Indoor PoE Midspan
- Power Cord
- Certifications & Standards
- IEEE802.3bt type 4 standard PDs
- IEEE 802.3af/at backward compatible
- FCC Part 15, Class B
- EN 55032 Class B
- EN 55024
- VCCI
- UL
- IEC
- EN 62368-1
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
